Hi,
We are using HTMLFormatProvider and PDFFormatProvider for converting HTML string to PDF file. The below issues are identified while converting PDF.
1. Text Foreground and Background color is not working in pdf.
HTML:
<p><span style="color: rgb(216, 55, 98); background-color: rgb(28, 122, 144); font-size: 30px;">Test</span></p>
We get the same issue even though we added below code.
foreach (Run run in document.EnumerateChildrenOfType<Run>()) { if (!run.Properties.HighlightColor.HasLocalValue) { run.HighlightColor = run.Shading.BackgroundColor.LocalValue; } }
Attached the PDF file
2. Strikeout is not working in PDF
Sample HTML:
<!DOCTYPE html>
<html>
<head>
<title>Page Title</title>
</head>
<body>
<p><span style="font-size: 24px;"><del>Delete Strike Through line in the paragraph</del></span></p>
</body>
</html>
attached the PDF file .
It would be appreciated , if you provide the solution for those issues
Regards,
Babu
A NullReferenceException is thrown when copying a sheet containing a chart with Marker whose FIll is null.
There is a workaround which should be applied before copying the sheet:
foreach (FloatingChartShape chart in wsPureCompTemplate.Charts)
{
foreach (SeriesGroup seriesGroup in chart.Chart.SeriesGroups)
{
foreach (SeriesBase series in seriesGroup.Series)
{
LineSeries lineSeries = series as LineSeries;
if (lineSeries != null && lineSeries.Marker != null && lineSeries.Marker.Fill == null)
{
lineSeries.Marker.Fill = new NoFill();
}
ScatterSeries scatterSeries = series as ScatterSeries;
if (scatterSeries != null && scatterSeries.Marker != null && scatterSeries.Marker.Fill == null)
{
scatterSeries.Marker.Fill = new NoFill();
}
}
}
}
Hello,
I'm using Telerik Documents Processing 2023.1.410
With WordsProcessing, if I add a table in a footer it will automatically add a space after the table
Here an example, my table is the same size as my image in background and I removed all margin of the section:
Here the code:
Footer footer = section.Footers.Add(HeaderFooterType.Default)
section.PageMargins = new Padding(0,96,96,0);
section.FooterBottomMargin = 0;
Table table = footer.Blocks.AddTable();
TableRow row = table.Rows.AddTableRow();
TableCell cell = row.Cells.AddTableCell();
Paragraph paragraph = cell.Blocks.AddParagraph();
paragraph.Inlines.AddRun("Something");
I didn't any properties to manage spaces around a Table like in Paragraph.
It can be reproduced without the image
Work around:
If I add a new paragraph at the end and remove all spaces of this paragraph then it works
Here the code added:
paragraph = footer.Blocks.AddParagraph();
paragraph.Spacing.SpacingAfter = 0;
paragraph.Spacing.SpacingBefore = 0;
paragraph.Spacing.LineSpacing = 0;
Regards,
Hervouet Thomas
Getting these Visual Studio warnings in using current Telerik.Maui and Telerik.Blazor in Build:
Detected package version outside of dependency constraint: Telerik.Documents.Spreadsheet.FormatProviders.Xls 2023.1.307 requires Telerik.Zip (= 2023.1.307) but version Telerik.Zip 2023.1.410 was resolved.
Detected package version outside of dependency constraint: Telerik.Documents.Spreadsheet.FormatProviders.OpenXml 2023.1.307 requires Telerik.Zip (= 2023.1.307) but version Telerik.Zip 2023.1.410 was resolved.
Detected package version outside of dependency constraint: Telerik.Documents.Flow.FormatProviders.Doc 2023.1.307 requires Telerik.Zip (= 2023.1.307) but version Telerik.Zip 2023.1.410 was resolved.
Detected package version outside of dependency constraint: Telerik.Documents.Fixed.FormatProviders.Image.Skia 2023.1.307 requires Telerik.Zip (= 2023.1.307) but version Telerik.Zip 2023.1.410 was resolved.
Detected package version outside of dependency constraint: Telerik.Documents.Fixed 2023.1.307 requires Telerik.Zip (= 2023.1.307) but version Telerik.Zip 2023.1.410 was resolved.
Detected package version outside of dependency constraint: Telerik.Documents.Core 2023.1.307 requires Telerik.Zip (= 2023.1.307) but version Telerik.Zip 2023.1.410 was resolved.
Detected package version outside of dependency constraint: Telerik.Documents.CMapUtils 2023.1.307 requires Telerik.Zip (= 2023.1.307) but version Telerik.Zip 2023.1.410 was resolved.
Please be sure similar warnings will not be generated in your upcoming June releases.
Thank you.
The project file references ONLY the two very latest Telerik Maui and Blazor Nuget packages, no other Telerik dlls, etc. It would seem the outdated references are internal to at least one of those nuget packages you furnish. I do not see that I have any means on my end to resolve them.
Here my only csproj Telerik references:
<PackageReference Include="Telerik.UI.for.Blazor" Version="4.2.0" />
<PackageReference Include="Telerik.UI.for.Maui" Version="5.1.0" />
