The StokeAlphaContant is not handled correctly when applied on a TextFragment:
Corrupted document when exporting "Courier New" subset.
Workaround - fully embed the font:
var pdfFormatProvider = new PdfFormatProvider();
pdfFormatProvider.ExportSettings.FontEmbeddingType = FontEmbeddingType.Full;
using Telerik.Windows.Documents.Fixed.FormatProviders.Pdf.Streaming;
using Telerik.Windows.Documents.Fixed.Model.Editing;
using Telerik.Windows.Documents.Fixed.Model.InteractiveForms;
using Telerik.Windows.Documents.Fixed.Model;
using Telerik.Documents.Primitives;
using System.Diagnostics;
using System.Reflection.Metadata;
using Telerik.Windows.Documents.Fixed.FormatProviders.Pdf;
namespace _1681158PdfInputFields
{
internal class Program
{
static void Main(string[] args)
{
ExportExamplePdfForm();
}
public static void ExportExamplePdfForm()
{
RadFixedDocument fixedDoc = new RadFixedDocument();
RadFixedPage fixedPage = fixedDoc.Pages.AddPage();
FixedContentEditor editor = new FixedContentEditor(fixedPage);
editor.Position.Translate(100, 100);
TextBoxField textBox = new TextBoxField("textBox");
fixedDoc.AcroForm.FormFields.Add(textBox);
textBox.Value = "Sample text...";
Size widgetDimensions = new Size(200, 30);
DrawNextWidgetWithDescription(editor, "TextBox", (e) => e.DrawWidget(textBox, widgetDimensions));
string fileName = "output.pdf";
File.Delete(fileName);
// File.WriteAllBytes(fileName, new PdfFormatProvider().Export(fixedDoc, TimeSpan.FromSeconds(15)));
string ResultFileName = "result.pdf";
File.Delete(ResultFileName);
using (PdfStreamWriter writer = new PdfStreamWriter(File.OpenWrite(ResultFileName)))
{
foreach (RadFixedPage page in fixedDoc.Pages)
{
writer.WritePage(page);
}
}
ProcessStartInfo psi = new ProcessStartInfo()
{
FileName = ResultFileName,
UseShellExecute = true
};
Process.Start(psi);
Console.WriteLine("Document created.");
}
private static void DrawNextWidgetWithDescription(FixedContentEditor editor, string description, Action<FixedContentEditor> drawWidgetWithEditor)
{
double padding = 20;
drawWidgetWithEditor(editor);
Size annotationSize = editor.Root.Annotations[editor.Root.Annotations.Count - 1].Rect.Size;
double x = editor.Position.Matrix.OffsetX;
double y = editor.Position.Matrix.OffsetY;
Block block = new Block();
block.TextProperties.FontSize = 20;
block.VerticalAlignment = Telerik.Windows.Documents.Fixed.Model.Editing.Flow.VerticalAlignment.Center;
block.InsertText(description);
editor.Position.Translate(x + annotationSize.Width + padding, y);
editor.DrawBlock(block, new Size(editor.Root.Size.Width, annotationSize.Height));
editor.Position.Translate(x, y + annotationSize.Height + padding);
}
}
}
Introduce Sanitize Document functionality.
https://experienceleague.adobe.com/en/docs/document-cloud-learn/acrobat-learning/advanced-tasks/redact
https://helpx.adobe.com/acrobat/using/removing-sensitive-content-pdfs.html
I have a simple program that imports a PDF, calls AcroForm.FlattenFormFields(), and calls Export() on the PdfFormatProvider. With the attached example PDF I am seeing the following exception.
System.NotImplementedException: 'The method or operation is not implemented.'
Stack Trace
at Telerik.Windows.Documents.Core.Fonts.Type1.Type1Format.Type1FontSource.GetCapHeight()
at Telerik.Windows.Documents.Core.Fonts.FontSource.get_CapHeight()
at Telerik.Windows.Documents.Fixed.FormatProviders.Pdf.Model.Elements.Fonts.FontDescriptor.CopyRequiredButType3FontPropertiesFrom(FontBase font)
at Telerik.Windows.Documents.Fixed.FormatProviders.Pdf.Model.Elements.Fonts.FontDescriptor.CopyPropertiesFrom(IPdfExportContext context, FontBase font)
at Telerik.Windows.Documents.Fixed.FormatProviders.Pdf.Model.Elements.Fonts.SimpleFontObject.CopyPropertiesFromOverride(IPdfExportContext context, FontBase font)
at Telerik.Windows.Documents.Fixed.FormatProviders.Pdf.Export.PdfExporter.WriteFontsFromContext(PdfWriter writer, IPdfExportContext context)
at Telerik.Windows.Documents.Fixed.FormatProviders.Pdf.Export.PdfExporter.Export(IRadFixedDocumentExportContext context, Stream output)
at Telerik.Windows.Documents.Fixed.FormatProviders.Pdf.ExceptionHandling.ExecutionHandler.TryHandleExecution[E](Action operation)
at Telerik.Windows.Documents.Fixed.FormatProviders.Pdf.PdfFormatProvider.ExportOverride(RadFixedDocument document, Stream output)
I have a simple program that imports a PDF, calls AcroForm.FlattenFormFields(), and calls Export() on the PdfFormatProvider. I am seeing the following exception during Import() on a signed W9 form a customer has uploaded into our system. Due to the sensitive nature of the document I cannot upload it, but below is the Sig section. I have tried other example signed PDFs which seem to work fine (See attached)
39 0 obj
<< /Type /Annot /Rotate 0 /AP 180 0 R /Rect [ 105.8515 149.2023 289.4443 261.1185
] /Border [ 0 0 0 ] /M (h<D[×¥\001.ƒ¶AB}«\006iÚ¿E@\024_”W±ÔÃ\030ÙL\020"É]a\012Ú6¡0\000¶Žm1@Ž)
/C [ 1 ] /DA (h<D[×¥\001.ƒ¶AB}«\006.\023âø‰\035\005íöu\002ÊÒ½ùwË@—‹måÿÚ[ ‹í!¨\001)
/F 4 /Subtype /Sig >>
endobj
Exception
System.NotSupportedException: 'Import of annotation with type Sig is not supported.'
Stack Trace
at Telerik.Windows.Documents.Fixed.FormatProviders.Pdf.Model.Elements.Annotations.AnnotationFactory.CreateUnsupportedAnnotationObject(PdfName type)
at Telerik.Windows.Documents.Fixed.FormatProviders.Pdf.Model.Converters.TypeAwareConverter`1.CreateInstance(Type type, PostScriptReader reader, IPdfImportContext context, PdfDictionary dictionary)
at Telerik.Windows.Documents.Fixed.FormatProviders.Pdf.Model.Converters.Converter.ConvertFromDictionary(Type type, PostScriptReader reader, IPdfImportContext context, PdfDictionary dictionary)
at Telerik.Windows.Documents.Fixed.FormatProviders.Pdf.Model.Converters.Converter.Convert(Type type, PostScriptReader reader, IPdfImportContext context, IPdfPrimitive value)
at Telerik.Windows.Documents.Fixed.FormatProviders.Pdf.Model.Converters.Converter.Convert(Type type, PostScriptReader reader, IPdfImportContext context, IPdfPrimitive value)
at Telerik.Windows.Documents.Fixed.FormatProviders.Pdf.Model.Types.PdfCollectionBase`1.ConvertElementToType[T](PostScriptReader reader, IPdfImportContext context, IPdfPrimitive element)
at Telerik.Windows.Documents.Fixed.FormatProviders.Pdf.Model.Types.PdfCollectionBase`1.TryGetElement[T](PostScriptReader reader, IPdfImportContext context, TIndex index, T& element)
at Telerik.Windows.Documents.Fixed.FormatProviders.Pdf.Model.Elements.DocumentStructure.Page.<>c__DisplayClass21_0.<CopyPageAnnotationsTo>b__0()
at Telerik.Windows.Documents.Fixed.FormatProviders.Pdf.ExceptionHandling.ExecutionHandler.TryHandleExecution[E](Action operation)
