Splitting a row leads to copying all rows below it. During that operation, the information for the row height is lost, when the previous row has a cell spanning on the split one, leading to a missing row in the exported document.
The issue is a regression introduced in R1 2021.
When a row has two cells and the content of the first one is large, the width of the second cell results in too small value while measuring and its content remains invisible.
Workaround: Set PreferredWidth to the second cell.
When a Table consisting of one TableRow that contains a TableCell with a Rowspan > 1 set, additional lines are added to the table.
Table table = new Table();
TableRow row = table.Rows.AddTableRow();
row.Cells.AddTableCell();
TableCell secondCell = row.Cells.AddTableCell();
secondCell.RowSpan = 2;
table.Measure();
table.Rows.AddTableRow();
According to the PDF Specification: The first entry in the table (object number 0) is always free and has a generation number of 65,535;
An invalid xref table:
xref 1 3 0000000010 00000 n 0000000124 00000 n 0000011290 00000 n
xref 0 4 0000000000 65535 f 0000000010 00000 n 0000000124 00000 n 0000011290 00000 n
.../AP<</N<</Off null/Yes 439 0 R>>...
Parameter name: form'
PdfFormatProvider: When Arial Narrow Bold fond is set in the document the font-weight is lost when converting to PDF.
Workaround:
var fontData = File.ReadAllBytes(@"C:\Downloads\arial-narrow\arialnb.ttf");
FontsRepository.RegisterFont(new System.Windows.Media.FontFamily("Arial Narrow"), FontStyles.Normal, FontWeights.Bold, fontData);
Currently, the text extraction is following the behavior (text distance) as exported with Adobe.
Provide a setting in TextFormatProvider in order to keep the original distance as in the PDF document.
When exporting PDF documents containing images different than Jpeg and Jpeg2000 the PdfProcessing is using by default the ImageSharp library in order to convert these images to Jpeg.
It seems there is an issue in the older version of the ImageSharp library: Saving a PNG as Jpeg only processes a part of the image on .NET 6.
Workaround: This issue seems to be fixed in the current version (2.0.0) of the ImageSharp library.
When a document containing a SignatureField is exported with the IsEncrypted property set to true, a not set UserPassword is required to open it, which makes it impossible to be opened.
Workaround: Exporting with AES256 encryption does not have this problem:
provider.ExportSettings = new PdfExportSettings
{
IsEncrypted = true,
EncryptionType = EncryptionType.AES256
};
URI Action with invalid mailto URL scheme - mailto:***@***.**(E-mail) can be imported but trying to merge or clone the document throws UriFormatException: 'Invalid URI: The hostname could not be parsed.'
Workaround: Remove the annotations that contain invalid Uri:
PdfFormatProvider provider = new PdfFormatProvider();
this.pdfDocument = provider.Import(memory);
foreach (var page in this.pdfDocument.Pages.ToList())
{
List<Link> links = page.Annotations.Where(a => a.Type == AnnotationType.Link).Select(a => a as Link).ToList();
foreach (var link in links)
{
Uri uri;
UriAction uriAction = link.Action as UriAction;
try
{
uri = uriAction.Uri;
}
catch (UriFormatException)
{
page.Annotations.Remove(link);
}
}
}
list-style is not imported correctly when importing from CSS classes defined in the same file
Case 1: importing from CSS classes defined in the same file
Case 2: inline style
<html>
<head>
</head>
<body>
<p>This is an unordered list with list-style:none</p>
<ul>
<li style="list-style:none;">Item 1</li>
<li style="list-style:none;">Item 2</li>
</ul>
<p>This is an unordered list with list-style:disc</p>
<ul>
<li style="list-style:disc;">Disc Item 1</li>
<li style="list-style:disc;">Disc Item 2</li>
<li>Some nested list </li>
</ul>
</body>
</html>
